HID pivCLASS R40
The contactless wall switch pivCLASS reader, our most popular profile
HID Global’s pivCLASS R40 wall switch contactless reader is suitable for use in security areas meeting the FIPS-201 criteria for “Controlled” access. When used in conjunction with HID Global’s pivCLASS Authentication Module (PAM), the pivCLASS R40 reader provides strong authentication ensuring that the card being presented is genuine; the data on the card has not been changed or manipulated; and the card is not a copy or clone of another card. The reader supports and reads any PIV-based card with an ISO14443 contactless interface and containing a Card Authentication Key (CAK) certificate.
Key Features:
- Popular wall switch format with LED access grant/deny indicator
- Configurable to operate in either Wiegand or PAM mode
- Supports reading legacy cards such as iCLASS, iCLASS SE and standard Prox
SPECIFICATIONS
Typical Maximum Read Range*
- Up to 1.5” for ISO14443 A cards
Dimensions:
- 3.3” X 4.8” x 1.0” (8.4 x 12.2 x 2.4 cm)
Legacy cards supported:
- Proximity: HID Prox, AWID and EM4102
13.56 MHz contactless smart cards supported:
- PKI-based FIPS 201 credentials including PIV, PIV-I, CIV, CAC, TWIC and FRAC
- iCLASS SE, iCLASS SR, standard iCLASS, SE for MIFARE Classic, SE for MIFARE DESFire EV1
Supported outputs in Wiegand mode:
- 40 bits
- 64 bits
- 75 bit GSA
- 128 bit UUIDs
- 200 bits full FASCN
Protocol:
- Wiegand mode – Wiegand
- PAM mode – HID Global pivCLASS protocol or CoreStreet Reader Protocol
Warranty:
- Lifetime
