Genetec Streamvault SV-1000E
Turnkey security appliance
Key features
- Turnkey appliance with Genetec™ Security Center pre-installed
- Video enterprise-grade SATA storage with RAID 5 configuration
- iDRAC9 Basic for local and remote server management
- Machine learning endpoint protection
Technical specifications
OS
Windows Server 2022
Processor
SV-1030E-R3:
1x Intel® Xeon® E-2334
Passmark: 13,189
Memory
16 GB DDR4 (2 x 8 GB DDR4)
Ethernet
SV-1030E-R3: 2x 1GbE RJ45
Peripherals
SV-1030E-R3: 1x USB 2.0 + 2x USB 3.0
Video output
SV-1030E-R3: 1x VGA
Integrated Dell Remote Access
Controller iDRAC 9 basic
Performance
Recording throughput: 250 Mbps
Redirection throughput: 40 Mbps
Playback throughput: 10 Mbps
Mechanical and environmental
Operating temperature
50°F to 95°F (10°C to 35°C)
Operating humidity
5 – 90% (non-condensing)
Compliance standards
Regulatory IEC 60950-1, European Norm EN 60950-1, CISPR 22/CISPR 24, EN55022/55024
Storage
Drive type
Hot-swap 3.5” SATA drives
OS drive
SV-1030E-R3:
1x 480GB SSD
Available drive sizes
4TB, 8TB, 12TB, 16TB, 20TB SATA
RAID controller
SV-1030E-R3:
PERC H730P (2GB NV Cache)
Data RAID level
RAID 5; RAID 6 & 10 available as options
Maximum data storage
120 TB (raw); 90.9 TB (usable)
